ABB CP-E 24/0.75 Power supply In:100-240VAC Out: 24VDC/0.75A
ABB CP-E 24/0.75 Power supply In:100-240VAC Out: 24VDC/0.75A
ABB CP-E 24/0.75 Power supply In:100-240VAC Out: 24VDC/0.75A - Image 2
ABB CP-E 24/0.75 Power supply In:100-240VAC Out: 24VDC/0.75A - Image 3
ABB CP-E 24/0.75 Power supply In:100-240VAC Out: 24VDC/0.75A - Image 4

ABB CP-E 24/0.75 Power supply In:100-240VAC Out: 24VDC/0.75A

£72.11 Incl. VAT

The CP-E 24/0.75 Is A Power Supply From The CP-E Range. The Primary Switch Mode Power Supply Offers A Wide Range Input Of 90-264 V AC And 120-375 V DC, Rated Input Voltage Is 100-240 V AC. The Rated Output Power Is 18 W, Rated Output Current Is 0.75 A At An Output Voltage Of 24 V DC. The Output Voltage Is Adjustable Within A Range Of 21.6 To 28.8 V DC. The Output Characteristic Is Hiccup-Mode. The Power Supply Allows Parallel Operation To Enable Redundancy. A Redundancy Unit Is Available As Accessory. · · · Power Supply

✓ In stock – Delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 1SVR427030R0000 Categories: , , Brand: Product Code: 2500375532

Description

Technical Specifications  Technical Specifications DC-power supply Width 22.5 mm Height 90 mm Power consumption 22.8 VA Width in number of modular spacings – Max. output current 1 – A Max. output current 2 0 A Max. output current 3 0 A Power output 18 W Nominal value output voltage 2 0 V Nominal value output voltage 1 24 V Nominal value output voltage 3 0 V Nominal value output current 2 0 A Nominal value output current 1 0.75 A Nominal value output current 3 0 A Depth 114 mm Recess height 90 mm Recess width 22.5 mm 2nd secondary output voltage 0 – 0 V 3rd secondary output voltage 0 – 0 V 1st secondary output voltage 24 – 24 V Rated supply voltage at DC 120 – 375 V Rated supply voltage at AC 50 Hz 90 – 264 V Rated supply voltage at AC 60 Hz 90 – 264 V Suitable for safety functions No Secondary voltage adjustable No Direct mounting possible No Modular version No Short-circuit-proof Yes Output voltage stabilized Yes Stabilized Yes Rail mounting possible Yes · Technical Data Sheet – Click to Download · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1580818 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1580819 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1580820 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1580821 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1580822 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1580823 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1580824 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1580825 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1580826 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1580827 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1580828
