Cembre BF Series M5 PVC Insulated Ring Terminal Stud 1.5-2.5mm² Blue
Cembre BF Series M5 PVC Insulated Ring Terminal Stud 1.5-2.5mm² Blue
Cembre BF Series M5 PVC Insulated Ring Terminal Stud 1.5-2.5mm² Blue - Image 2
Cembre BF Series M5 PVC Insulated Ring Terminal Stud 1.5-2.5mm² Blue - Image 3
Cembre BF Series M5 PVC Insulated Ring Terminal Stud 1.5-2.5mm² Blue - Image 4

Cembre BF Series M5 PVC Insulated Ring Terminal Stud 1.5-2.5mm² Blue

Pack of 100

£6.90 Incl. VAT

1.5mm²-2.5mm² PVC insulated ring terminal M5 stud blue · · · PVC insulation · · -20°C to +80°C Temperature Range · · Manufactured from Electrolytic Copper Wire with a purity greater than 99.9% · · Electrolytically tin-plated to avoid oxidisation · · Annealed to guarantee optimum ductility · · Facilited Introduction of the conductor

✓ In stock – Delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: BF-M5 Categories: , , Brand: Product Code: 2500221849

Description

Technical Specifications  Technical Specifications Solderless copper terminals for copper conductors Colour insulation Blue Sleeve form Short Material Copper Surface protection Tinned Insulation Polyvinyl chloride (PVC) Flange shape Ring shape Bolt dimension (metric) 5 Max. current (Imax) – A For pull protected connections No Suitable for fine strand conductors No Suitable for flat conductors No Suitable for round conductors Yes According to DIN No Reel packaging No AWG-range 16 – 14 Nominal cross section 1.5 – 2.5 mm² Useful for stranded conductors Yes Suitable for solid cores No Suitable for high temperatures (to 650 °C) No Suitable for insulated varnish No · Technical Data Sheet – Click to Download
