Description

Technical Specifications  Technical Specifications Single- and multi-pole terminal strip Connection position Sideways Colour White Material insulation body Thermoplastic Type of electrical connection 1 Screw connection Type of electrical connection 2 Screw connection Rated voltage 400 V Width – mm Number of poles 12 Depth – mm Width/grid dimension 20.1 mm Connectable conductor cross section fine-strand without cable end sleeve 0 – 10 mm² Rated current In 57 A Height at lowest possible mounting height 16.2 mm Number of clamp positions per pole 2 Drill hole distance centrically 11.5 mm Length 131.4 mm Height – mm Operating temperature -25 – 50 °C Connectable conductor cross section fine-strand with cable end sleeve 0 – 6 mm² Connectable conductor cross section solid-core 0 – 10 mm² Connectable conductor cross section multi-wired 0 – 10 mm² Explosion-tested version ‘Ex e’ No Closing plate required No Transparent No Halogen free No · Technical Data Sheet – Click to Download
