Description

Technical Specifications  Technical Specifications Single- and multi-pole terminal strip Connection position Sideways Material insulation body Thermoplastic Colour White Type of electrical connection 2 Screw connection Type of electrical connection 1 Screw connection Width – mm Height – mm Width/grid dimension 15.8 mm Rated voltage 400 V Depth – mm Length 92.8 mm Number of poles 12 Drill hole distance centrically 7.9 mm Number of clamp positions per pole 2 Rated current In 24 A Height at lowest possible mounting height 12.6 mm Connectable conductor cross section fine-strand with cable end sleeve 0 – 2.5 mm² Operating temperature -25 – 50 °C Connectable conductor cross section fine-strand without cable end sleeve 0 – 4 mm² Connectable conductor cross section solid-core 0 – 4 mm² Connectable conductor cross section multi-wired 0 – 4 mm² Explosion-tested version ‘Ex e’ No Transparent No Closing plate required No Halogen free No · Technical Data Sheet – Click to Download
