Description

Technical Specifications  Technical Specifications Power cable < 1 kV, for fixed installations Conductor category Class 2 = stranded Armouring/reinforcement None Sheath colour Blue Conductor material Copper Core colour Blue Core identification Colour Nominal voltage U 750 V Nominal cross sectional area of conductor 2.5 mm² Number of cores 1 Low temperature resistant according to EN 60811-504+505+506 No Twisted cores No Permitted cable outer temperature during assembling/handling 0 - 80 °C Outer diameter approx. 3.7 mm Max. conductor temperature 90 °C Nominal voltage U0 450 V Conductor Diameter 2.5 mm Oil resistant according to IEC 60811-404 No · Technical Data Sheet – Click to Download
