Eaton EMCH316 Memshield 3 3-Pole 16A MCB Type C 10/15kA 54 x 80 x 75mm
Eaton EMCH316 Memshield 3 3-Pole 16A MCB Type C 10/15kA 54 x 80 x 75mm
Eaton EMCH316 Memshield 3 3-Pole 16A MCB Type C 10/15kA 54 x 80 x 75mm - Image 2
Eaton EMCH316 Memshield 3 3-Pole 16A MCB Type C 10/15kA 54 x 80 x 75mm - Image 3

Eaton EMCH316 Memshield 3 3-Pole 16A MCB Type C 10/15kA 54 x 80 x 75mm

£71.51 Incl. VAT

The Eaton MCBs are fitted with box clamp terminals suitable for use with cables up to 25mm² and have a unique box clamp barrier to prevent incorrect cable insertion. This 10/15kA MCB are designed & tested in accordance with IEC 60898 & IEC 60947-2. It is certified by KEMA. Type C MCBs are most commonly used in commercial and general applications where there are lighting or motor loads involving high switching surges that may cause unwanted operation of type B devices. Suitable for 230/400 VAC systems and are calibrated for use at 40°C. · · · DIN rail mountable · · Suitable for use with both pin and comb type busbar systems · · Suites RCBOs, RCCBs and isolators · · Positive contact is flag indicator · · Operating temperature: -25 to 55 °C · · Impulse withstand voltage: 5kV · · Energy limiting class 3

15 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: EMCH316 Categories: , , Brand: Part Number: 2500331189

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Tripping characteristic (type/curve) C Voltage type AC Rated current 16 A Rated insulation voltage Ui 440 V Current limiting class 3 Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Number of poles (total) 3 Rated impulse-withstand voltage (Uimp) 4 kV Number of protected poles 3 Pollution degree 2 Over voltage category 3 Width in number of modular spacings 3 Rated voltage 240 V Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 0 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 0 kA Recess depth 70.5 mm Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 55 °C Explosion-proof No Concurrently switching N-neutral No Additional equipment possible Yes Flush-mounted installation Yes
