Eaton Fuse-link LV 100 A AC 500 V BS88/A4 25 x 110 mm gL/gG BS
Eaton Fuse-link LV 100 A AC 500 V BS88/A4 25 x 110 mm gL/gG BS
Eaton Fuse-link LV 100 A AC 500 V BS88/A4 25 x 110 mm gL/gG BS - Image 2

Eaton Fuse-link LV 100 A AC 500 V BS88/A4 25 x 110 mm gL/gG BS

£12.71 Incl. VAT

CEO100 is a Low Voltage Fuse Link, with offset bolted tags. This fuse is Q1 fusing factor for general purpose. The range of British standard Low Voltage Fuse Link size is A4, for protection of general industrial applications. · · · Breaking Capacity: 80kA @ 550V AC · · Current Rating: 100A · · Length: 110mm · · Mounting Type: Bolt-in Mount · · Voltage Rating: 550V AC · · Fixing Centre: 94mm

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: CEO100 Categories: , Brand: Product Code: 2500013180

Description

Technical Specifications  Technical Specifications HRC fuse Colour code None Type of fuse status indicator None Fuse system according to IEC 60269 Fuse system E Utilization category gG (cable protection/equipment protection) Fuse construction type according to IEC 60269 A4 Mounting holes M8 Current type AC Rated current 100 A Breaking capacity 80 kA Centre-to-centre distance of connections 94 mm Rated voltage AC 500 V Power loss at rated current 8.5 W
