Eaton MCB TP Type D 50A 10/15kA
£115.30 Incl. VAT
EM miniature circuit-breaker, 3 pole, trip type: D, rated operational current In: 50 A, rated switching capacity according to IEC/EN 60947-2: 15 kA, switchgear for residential and non-residential applications · · · Short circuit rating 10kA to IEC 60898 and 15kA to IEC 60947-2 · · Comprehensive range of accessories suitable for subsequent installation · · 3-position DIN rail clip, permits removal from existing busbar system · · Rated breaking capacity 10 kA according to IEC/EN 60898-1 · · Tripping characteristics B, C and D · · Rated currents up to 63 A
Out of stock
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) D Voltage type AC Recess depth 70.5 mm Degree of protection (IP rating) IP20 Rated insulation voltage Ui 440 V Rated current 50 A Rated voltage 400 V Over voltage category 3 Width in number of modular spacings 3 Current limiting class 3 Pollution degree 2 Rated impulse-withstand voltage (Uimp) 4 kV Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Connectable conductor cross section solid-core 1 – 25 mm² Frequency 50 – 60 Hz Number of protected poles 3 Number of poles (total) 3 Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Concurrently switching N-neutral No Additional equipment possible Yes Flush-mounted installation No Explosion-proof No · Technical Data Sheet – Click to Download
