Product image supplied by the manufacturer
Fusegear

Eaton Fuse Link HRC Offset Bolted Tags 6A

Brand: EatonProduct code: TIA6Go Magpie Ref: 5060062385915

Red Spot industrial offset bolted tags fuse links are specifically designed for the protection of general industrial applications, e.g. power distribution and cable protection. · · · BS reference: A2 · · gG characteristics for cable protection · · Good peak and let-through current limitation · · 1: 1: 6 selective coordination ratio between “minor” and “major” fuse · · Power loss values well within the limits of IEC 60269 · · Compatible with Camaster Compact 32A CM32FC and Red Spot fuse holder 32A RS32 · · Pre-arching: 22 · · Total at rated voltage: 150 · · 73mm fixing centre · · 660-690V AC/460V DC

£7.62inc VAT£6.35 ex VAT
In stock
UK deliveryStandard shipping is £2.99 inc VAT on eligible orders. Final delivery options are confirmed at checkout.
Quantity
1
✓ Secure checkout✓ UK customer support✓ Trusted suppliers
PRODUCT INFORMATION

Description

Technical Specifications  Technical Specifications HRC fuse Colour code None Type of fuse status indicator None Fuse system according to IEC 60269 Fuse system E Utilization category gG (cable protection/equipment protection) Fuse construction type according to IEC 60269 A2 Mounting holes M5 Breaking capacity 80 kA Centre-to-centre distance of connections 73 mm Current type AC/DC Rated voltage AC 660 V Rated current 6 A Rated voltage DC 460 V · Technical Data Sheet – Click to Download
