Gigamedia Cable CAT5e 4P U/UTP PVC ECA Grey PB 305m
Gigamedia Cable CAT5e 4P U/UTP PVC ECA Grey PB 305m
Gigamedia Cable CAT5e 4P U/UTP PVC ECA Grey PB 305m - Image 2

Gigamedia Cable CAT5e 4P U/UTP PVC ECA Grey PB 305m

£108.35 Incl. VAT

The GIGAMEDIA CAT5e cables are data transmission cables designed for applications in frequency range up to 100 MHz. These cables meets and exceed the requirements of ISO 11801 CAT5e, ensuring to get Class D Permanent Link performance when combined with Gigamedia CAT5e jacks. · · · Packaging: 305m box · · Complies with standards: ANSI/TIA-568-C.2 EN 50173 ISO/IEC 11801 · · Applications: IEEE 802.3: 10Base-T; 100Base-T; 1000Base-T; PoE · · Sheath colour: grey RAL 7032 · · Diameter of outer sheath: 4.6mm · · Frequency range: from 0 to 100 MHz · · Impedance characteristics: 100 O · · Sheath: PVC · · NVP: 70 % · · Conductor copper gauge 25 AWG

✓ In stock – Delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: GGM C5EU4PPVCU3 Categories: , , Brand: Product Code: 2501674390

Description

Technical Specifications  Technical Specifications Data and communication cable Sheath colour Grey Individual screen type None Overall screen type None Reaction-to-fire according to EN 13501-6: Acidity None Reaction-to-fire according to EN 13501-6: Flaming droplets/particles None Reaction-to-fire according to EN 13501-6: Smoke production None Stranding element Pairs Reaction-to-fire according to EN 13501-6: Class Eca Category 5E Sheath material Polyvinyl chloride (PVC) Conductor category Class 1 = solid Core identification Colour Weight – kg/km Nominal cross sectional area of conductor 0 mm² Conductor Diameter 0 mm Number of cores 8 NVP value 70 % Min. permitted bending radius, stationary application/permanent installation – mm Outer diameter approx. 4.6 mm Number of stranding elements 8 Min. permitted bending radius, moving application with forced guidance – mm Min. permitted bending radius, moving application/free movement – mm Permitted cable outer temperature during assembling/handling 0 – 50 °C Permitted cable outer temperature after assembling without vibration -20 – 60 °C Compatible with Grade2TV according to XP-C 90-483 No Compatible with Grade3TV according to XP-C 90-483 No Certified for shipboard application No Longitudinal water blocking cable No Radial water blocking cable No Core identification according to HD 308 S2 No Suitable for use as telephone cable No Suitable for use as computer data cable No Suitable for use as signalling cable No Low smoke according to IEC 61034-2 No Oil resistant according to IEC 60811-404 No Halogen free according to IEC 60754-2 No Suitable for underground installation No · Technical Data Sheet – Click to Download
