Lewden 6A Trip Curve C RCD Class A Residual Current 30mA 10kA RCBO
£49.78 Incl. VAT
A fully comprehensive range of 10kA RCBOs, which provides protection for cables, filament lighting circuits, heating loads and domestic applications, as well as protection against earth leakage, overload and short circuits. Lewden 10kA RCBOs are fully compatible with the TP&N range which is the complete solution to managing the distribution of electricity in commercial premises such as offices, warehouses, factories, schools, hospitals etc. · · · Designed and tested for use with Lewden branded distribution boards. · · Residual current circuit breaker with integral overcurrent protection. · · Class AC & A. · · Single module RCBOs are suitable for use in TN-S, TN-C-S, & TT network systems.
15 available – delivery in 1–2 days
Description
Technical Specifications Technical Specifications Earth leakage circuit breaker/RCBO Recess depth 761 mm Rated current 6 A Rated voltage 230 V Rated insulation voltage Ui – V Pollution degree – Rated impulse-withstand voltage (Uimp) – kV Over voltage category – Number of poles (total) 2 Rated short-circuit breaking capacity IEC 60947-2 – kA Current limiting class – Rated fault current 3 A Connectable conductor cross section multi-wired – mm² Connectable conductor cross section solid-core – mm² Rated short-circuit breaking capacity according to EN 61009 10 kA Rated short-circuit breaking capacity Icn according to EN 61009-1 – kA Width in number of modular spacings 1 Surge current capacity – kA Number of protected poles – Ambient temperature during operating – °C Concurrently switching N-neutral No Flush-mounted installation No With interlocking device No Anti-nuisance tripping version No · Technical Data Sheet – Click to Download
