MCCB Triple Pole 63A 25Ka Thermal Magnetic

Description

Technical Specifications  Technical Specifications Moulded case circuit breaker (MCCB) Position of connection for main current circuit Front Type of electrical connection of main circuit Frame clamp Degree of protection (IP rating) IP20 Device construction Built-in device fixed built-in technique Type of control element Rocker lever Overload release current setting 50 – 63 A Rated voltage 440 – 440 V Number of poles 3 Number of auxiliary contacts as normally open contact 0 Rated permanent current Iu 63 A Number of auxiliary contacts as normally closed contact 0 Number of auxiliary contacts as change-over contact 0 Rated short-circuit breaking capacity Icu at 400 V, 50 Hz 25 kA Adjustment range short-term delayed short-circuit release 0 – 0 A Adjustment range undelayed short-circuit release 380 – 630 A Motor drive optional No DIN rail (top hat rail) mounting optional Yes Complete device with protection unit Yes With integrated under voltage release No Integrated earth fault protection No Switched-off indicator available No Suitable for DIN rail (top hat rail) mounting No Motor drive integrated No · Technical Data Sheet – Click to Download
