RCBO SP Class A Type C 6A 30mA 10kA Plug-On
£53.89 Incl. VAT
The Schneider LoadCentre KQ SEE106C03 is a 6 amp 30 milliamp single pole RCBO. This Schneider LoadCentre KQ RCBO has a click-in busbar for speed of installation and guaranteed connection, has a 10kA breaking capacity and has a trip free mechanism that operates even when the toggle is locked on. The LoadCentre KQ MCB’s are lockable in the on or off position and is suitable for any Schneider Loadcentre KQ A and B type distribution boards. · · · BS EN 61009 Compliant · · 10kA Breaking Capacity · · Speed of connection of Plug-On devices – guaranteed connection Plug-On devices · · Control type toggle · · Thermal-magnetic trip unit technology · · of detectors · · Quick and simple installation · · Can only be used with AlarmSense systems · · It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. · · The Ue operational voltage is 150VAC to 230VAC.
143 available – delivery in 1–2 days
Description
Technical Specifications Technical Specifications Earth leakage circuit breaker/RCBO Tripping characteristic (type/curve) C Mounting method DIN rail Rated current 6 A Rated insulation voltage Ui 400 V Width in number of modular spacings 2 Rated voltage 230 V Rated short-circuit breaking capacity Icn according to EN 61009-1 10 kA Recess depth 70 mm Over voltage category 3 Pollution degree 3 Number of poles (total) 2 Connectable conductor cross section multi-wired 1 – 16 mm² Connectable conductor cross section solid-core 1 – 16 mm² Rated fault current 0.03 A Number of protected poles 1 Current limiting class 3 Surge current capacity 0.25 kA Rated impulse-withstand voltage (Uimp) 4 kV Ambient temperature during operating -25 – 55 °C Concurrently switching N-neutral Yes Anti-nuisance tripping version No Suitable for flush-mounted installation No With interlocking device No · Technical Data Sheet – Click to Download · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2200034
