Wylex MCB 50A SP Type B 6kA
£4.62 Incl. VAT
This Miniature Circuit Breaker is a thermal-magnetic current limiting type, having a compact construction which has been achieved by not only minimising the number of parts but also the number of welded joints and connections. The MCB has an easy to opera · · · Single pole MCB, 50A B curve · · Energy limiting Class 3 · · Plug in · · Type B · · Trip Type: Type B · · Short circuit rating 6 kA · · Voltage 240V · · IP20
18 available – delivery in 1–2 days
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Rated insulation voltage Ui 400 V Current limiting class 3 Tripping characteristic (type/curve) B Over voltage category 3 Rated voltage 230 V Rated current 50 A Recess depth 73 mm Width in number of modular spacings 1 Rated impulse-withstand voltage (Uimp) 4 kV Number of protected poles 1 Additional equipment possible No Ambient temperature during operating -5 – 40 °C Connectable conductor cross section multi-wired 0.75 – 25 mm² Frequency 50 – 50 Hz Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Number of poles (total) 1 Flush-mounted installation No Concurrently switching N-neutral No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
