Basiccharge EV Charging Pedestal 3 Phase Black 1 x Type 2 (IEC 62196) Charging Socket Up To 22kW (32A) 1 x 32A 400V AC
Basiccharge EV Charging Pedestal 3 Phase Black 1 x Type 2 (IEC 62196) Charging Socket Up To 22kW (32A) 1 x 32A 400V AC
Basiccharge EV Charging Pedestal 3 Phase Black 1 x Type 2 (IEC 62196) Charging Socket Up To 22kW (32A) 1 x 32A 400V AC - Image 2
Basiccharge EV Charging Pedestal 3 Phase Black 1 x Type 2 (IEC 62196) Charging Socket Up To 22kW (32A) 1 x 32A 400V AC - Image 3

Basiccharge EV Charging Pedestal 3 Phase Black 1 x Type 2 (IEC 62196) Charging Socket Up To 22kW (32A) 1 x 32A 400V AC

£1,818.07 Incl. VAT

The BASICCHARGE is a simplistic and affordable EV charging pedestal. This versatile charger’s integrated LED amenity lighting also provides greater visibility of the charging bays and surrounding areas.This future-proof OCPP compliant pedestal can offer a simple plug & charge or pay-to-charge solution via the EV driver’s smartphone and/or RFID card/fob through any chosen OCPP back office management system. · · · Plug & charge, mobile app or RFID controlled charging · · Over-the-air firmware / software updates · · Built-in AC overload & fault current protection (RCBO) · · LED amenity lighting head (Photocell controlled)

4 in stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: ROLEC0213B Categories: , Brand:

Description

Technical Specifications  Technical Specifications Charging device for electric vehicles Mounting method Floor fastening Impact resistance (IK rating) IK10 Housing material Steel Installation side connection model 3-phase Degree of protection (IP rating) IP54 Frequency 50/60 Hz Voltage type of supply voltage AC Open Charge Point Protocol (OCPP) version 1.6 Height 1130 mm Width 205 mm Radio standard 4G Yes Floor mounting Yes Depth 205 mm Max. output current DC 32 A Number of socket outlets Type 2 1 Max. power per charging point 22 kW Number of charging units 1 Networkable via Wi-Fi Yes Networkable via LAN Yes · Technical Data Sheet – Click to Download
