Quantum EV Single Phase Black 4 x Type 2 (IEC 62196) Charging Sockets Up To 7.4kW (32A) Per Socket 2 x 63A 230V AC

Quantum EV Single Phase Black 4 x Type 2 (IEC 62196) Charging Sockets Up To 7.4kW (32A) Per Socket 2 x 63A 230V AC

£4,365.07 Incl. VAT

The QUANTUM EV charging pedestal is a sophisticated and resilient EV charging point, providing a combination of durability and impeccable design for all locations. This charger’s integrated LED amenity lighting also provides greater visibility of the charging bays and surrounding areas.This future-proof OCPP compliant pedestal can offer a simple plug & charge or pay-to-charge solution via the EV driver’s smartphone and/or RFID card/fob through any chosen OCPP back-office management system. · · · Plug & charge, mobile app or RFID controlled charging · · TruePEN PME fault detection (no earth rod required) · · Cable lock feature (can be permanently locked by user) · · Integrated RFID reader(s)

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: ROLEC0425B Categories: , Brand:

Description

Technical Specifications  Technical Specifications Charging device for electric vehicles Installation side connection model Single phase Impact resistance (IK rating) IK10 Degree of protection (IP rating) IP54 Frequency 50/60 Hz Voltage type of supply voltage AC Open Charge Point Protocol (OCPP) version 1.6 Housing material Aluminium Width 375 mm Number of charging units 4 Tube mounting possible No Suitable for wall mounting No Max. output current DC 32 A Max. power per charging point 7.4 kW Number of socket outlets Type 2 4 Depth 271 mm Height 1440 mm Floor mounting Yes Radio standard 4G Yes Networkable via Wi-Fi Yes Networkable via LAN Yes · Technical Data Sheet – Click to Download
